Bigger engine than BS4 for robust performance
Higher power & torque in comparison to BS4 for excellent trip performance
Pure SCR for BS6 with vertical exhaust module
Availability of Ultimaax suspension as an option
Top features- 3 mode FE switch, Hill start assist,, Engine Brake, Unitised bearing (O), Adjustable steering
GVW increased form 25 ton to 28 ton from August 2018 as per IAL norms
-
Payload increased by 3 ton from August 2018 due to IAL norms
-
16 m³ = Aggregates, Sand, Soil, Iron ore, etc.
14 m³ = Boulder
-
-
-
This engine is sold globally and it's BS6 version is already used in many countries
TML migrated to bigger engine for enhanced power & torque output in BS6
6 cylinder engine offers the assurance of heavy duty performance & durability
Acceleration & Speed will be higher even with lesser pressing of accelerator
Higher torque to weight ratio in BS6 for better pick-up, higher load pulling and better gradient climbing
Cummins ISBe 6.7 has global compatibility with BOSCH FIP
Light, Medium & Heavy mode button for different load & gradient scenario for higher KMPL
-
Non EGR strategy allows better diesel combustion and less soot emission. vertical mounting of exhaust system ensures safety of the system
Bigger clutch size along with higher engine torque will help in achieving very long life of clutch assembly
Gearbox comes with 1 Crawler & 8 Forward gears. It has pneumatic assist for decreasing shifting efforts
Crawler gear helps in case vehicle gets stuck due to heavy load on gradients
Proven double differential axle of Tata motors
Higher RAR of 6.14 helps in higher load pulling and climbing ability
Engine brake has better downhill breaking response and safety along with longer service brake liner life and KMPL
Semi elliptical suspension is rugged in design which is suitable for any load, any surface. Parabolic suspension offers better cabin comfort
Bogie suspension is for heavier loads and patchy surfaces. Ultimaxx suspension provides same benefit of bogie, additionally it has lower maintenance, Longer warranty & lesser weight
In BS6 the frame has been straightened for longer tyre life
The tank has been changed from metallic to polymer for higher strength and low contaminations
Tank size has been increased by 25 litres in BS6
11x20 MT is suitable for medium duty mining
Considerable TAW increase in BS6 for higher load pulling and climbing ability
-
-
Signa Day Cabin
Fixed cabin for lower vibrations
Driving comfort
Driving comfort
Driving comfort
AdBlue gauge, Battery voltage, Digital clock, Distance to empty, Service reminder, Average fuel economy etc.
-
Better visibility of objects which are close to the vehicle in the front and the co-driver side
Easy ingress and egress
Fast mobile charging with speed of 2.4V
"Fleet Edge telematics by Tata as standard fitment with Geo fencing, Tracking, Anti fuel theft & other features"
Prevents roll back for three seconds on gradients
Alarms customer in case there is sudden drop of diesel level in the fuel tank
-
Better visibility of the vehicle from rear. LEDs have longer life than regular bulbs
No hub greasing expense/downtime for 5500 Hours
Protection from sunlight
-
-
-
-
-
-
Kept similar as BS4
-
-
-
